BlackVue B-130X 30 Hours Power Magic Ultra Battery for Extended Parking Mode
THE ULTIMATE SUPPLEMENTARY DASH CAM POWER SOURCE
Power Magic Ultra Battery recharges when driving and powers your dashcam when ignition is off. Its sleek compact enclosure houses a large-capacity battery (12.8V / 7,500mAh / 96Wh).
- Fast-Charging: Power Magic Ultra Battery reaches a full charge in 50 minutes when hardwired (90 minutes if connected to the cigarette lighter socket).
- Long-lasting: Parking Mode can last more than 30 hours with a single-channel DR900X Plus (19 hours with the dual-channel version).
- Connected: check the battery’s status wirelessly with the BlackVue App.
SIMPLE OR HARDWIRED INSTALLATION
Power Magic Ultra Battery supports two installation modes and automatically adapts its charging current accordingly.
- Simple installation Just plug the battery into the 12V auxiliary power outlet (cigarette lighter socket) of your vehicle. Charging current: 5A – Charging time: approx. 90 minutes.
- Hardwired installation For the fastest charging speed, connect the battery to the fuse panel. Charging current: 9A – Charging time: approx. 50 minutes.
12V/24V COMPATIBILITY AND USB POWER OUTLET
Use in any vehicle. Charge your accessories.
- 12V/24V compatibility: the Power Magic Ultra Battery (B-130X) supports both 12V and 24V electrical systems. This means it is compatible with most individual and commercial or heavy-duty vehicles on the market.
- 5V USB (2A max): with its USB power output, you can charge any accessory, such as a phone or a Wi-Fi hotspot to keep your Cloud dashcam connected while in Parking Mode.
CHECK DETAILED BATTERY INFO FROM YOUR PHONE
- Connect wirelessly to the Power Magic Ultra Battery with the BlackVue App.
- When charging, the app displays charge percentage, charging voltage and expected remaining time until full charge.
- When vehicle ignition is off, the app shows the remaining Parking Mode time based on the dashcam’s power consumption.
- Fuel Gauge IC: the fuel gauge integrated circuit keeps track of electric currents—charge and discharge—over time, to give you the most accurate battery info.
SPECIFICATION
- Model Name Power Magic Ultra Battery (B-130X)
- Capacity 12.8 V / 7,500 mAh / 96 Wh
- Product Dimensions Black / 152.7mm (W) X 206.0mm (L) X 33.6mm (H) / 1,537g
- Operation Temperature Charging Temperature: 0 °C − 45 °C (32 °F − 113 °F) Discharging Temperature: -10 °C − 60 °C (14 °F − 140 °F)
- Storage Temperature -20 °C − 45 °C (-4 °F − 113 °F)
- High Temp Cut Off High temperature: Approx. 80 °C (176 °F) / Low temperature: Below 0 °C (32 °F)
- Backup Battery LiFePo4
- Input Power 12V system: – Cigarette lighter plug: 11 V–18 V / 7.2 A (max) – Hardwired: 11 V–18 V / 13.0 A (max)
- 24V system: – Cigarette lighter plug: 22.5 V–30 V / 3.6 A (max) – Hardwired: 22.5 V–30 V / 6.4 A (max)
- Power Consumption Hour Cigarette lighter plug: 14.2 V / 5 AHardwired: 14.2 V / 9 A Cigarette lighter plug (standard 5 A charging): Approx. 90 minsHardwired (rapid 9 A charging): Approx. 50 mins Approx. 30 hours (based on a single dashcam that consumes 3 W)
- Output current / Quiescent current Dashcam port: 11 V–14.2 V / 2 A (max)
- Others USB port: 4.75V–5.2 V / 2A (max)
WHATS INCLUDED
- Power Magic Ultra Battery (B-130X)
- Cigarette lighter plug power cable (male)
- Output cable for dashcam (Female cigarette lighter socket)
- Hardwiring power cable
- Dashcam hardwiring power cable
- Fuse tap kit (3 types)
- 2 velcro strips
- User Manual
WORKS WITH
- BlackVue
- Thinkware
- Garmin
- Nextbase
- Mio
- Viofo
