Kicker DSC69304 - 6 x 9" 160 x 230mm 360 Watts 3 Way Rear Triaxial Car Speakers
A drop-in coaxial upgrade with the flexibility to fit nearly any vehicles doors for a vast improvement over factory sound.
DS Series 6x9" 3-Way
The DS Four-Inch Triaxial (3-Way) Speakers are a great way to upgrade the sound in your car.
Using zero protrusion PEI tweeters ensures you get every bit of clarity you need, without interfering with factory grilles. A stamped steel framework supports a ribbed, UV-treated foam surround and rigid polypropylene cone with EVC™ (Extended Voice Coil) technology, for the best sonic quality. Add a DX amplifier to increase the level and quality of the volume in your ride.
These DS speakers work best with 90 watts of recommended power. See below for more details.
Key Features
- Model: DSC693
- Speaker Design: 3 - Way
- Woofer [in, mm]: 6x9, 160x230
- Mid [in, mm]: 2, 50
- Tweeter [in, mm]: 1/2, 13
- Rated Impedance [Ω]: 4
- Peak Power Handling [Watts]: 360
- Continuous Power Handling [Watts RMS]: 90
- Sensitivity [1W, 1m]: 92
- Frequency Response [Hz]: 30-20k
- Mounting Hole Diameter [in, mm]: 5-5/8 x 8-7/16, 143x215
- Top Mount Depth [in, mm]: 1/2, 12
- Bottom Mount Depth [in, mm]: 3-3/16, 81
- Tweeter Protrusion [in, mm]: 0
- Grilles: Yes
- Tweeter Magnet Material: Neodymium
- Tweeter Dome Material: PEI (polyether imide)
- Tweeter Design: Balanced dome
- Woofer Cone Material: Polypropylene
- Woofer Surround Material: Polyester foam
