Phoenix Gold RX2400.4 - 400 Watts RMS 4 Channel Class A/B Car Amplifier Amp
RX2 400.4 is a powerful 4 channel 400W Class A/B amplifier delivering massive power to support your systems needs. Configure as a 4ch for an active components setup or as a front/rear stage amplifier. How about for a full system? Setup as 3ch mode you can run your front stage and a subwoofer. Configure in 2ch mode for 200 watts x2 on whatever you choose. Anyway you configure it, you will be rewarded with efficient sound and musical quality while wrapped in a sleek, low profile chassis designed for versatility.
RX2400.4 Product Features:
- Class A/B Topology
- Small Footprint Chassis Design
- Robust Unregulated Power Supplies
- Rotatable Badging for installation flexibility
- High level Inputs for Easy OEM Integration
- Audio Precision Quality Control Verification
RX2400.4 Product Specifications:
- RMS Power Ratings listed at less than 1% THD @ 14.4v
- Number of Channels: 4
- 4Ω: CH 1 - 4 75W x 4
- 2Ω: CH 1 - 4 100W x 4
- 2CH Mode: 1+2 4Ω Bridged & 3+4 4Ω Bridged 200W x 2
- 3CH Mode: 1/2 4Ω Stereo & 3+4 4Ω Bridged 75W x 2 + 200W x 1
- 3CH Mode: 1/2 2Ω Stereo & 3+4 4Ω Bridged 100W x 2 + 200W x1
- Total RMS Power (Sum of rated power): 400 Watts
- Bridgeable:
- Crossover Mode: FULL/HP/LP
- CH 1 - 4 50Hz - 200Hz @ 12dB / Oct Linkwitz Riley
- Input Channels: 4CH F/R, 3 CH FRONT, 2 CH FRONT
- Input Mode: Unbalanced / Balanced
- Processing: Bass Boost 0dB / +6dB / +12dB @45hz
Input Sensitivity:
- .2v - 6v Unbalanced RCA Low-Level
- .5v - 15v Balanced Hi-Level Harness
- Signal to Noise (@ CEA Standard): >80dB
- Frequency Response: Full Range CH 1 - 4 10Hz - 40kHz
- Topology Class: A/B
- Heatsink Type: Extruded Aluminum
- Cooling Type: Radiation
- Operating Voltage: 8V to 16V
- Switchable Auto-Turn On: No
- Power Supply Type: Unregulated
- Power TerminalS: 4 Gauge
- Speaker Terminal: 10 Gauge
- On Board Fusing: 2 x 30A ATC
- Recommended Inline Fuse: 50A
Dimensions (L x W x H): 15.74” x 8.11” x 1.98” - 400mm x 206mm x 50.5mm
